core components
PLC, Motor
warranty
1 Year
machinery test report
Provided
video outgoing-inspection
Provided
Weight (KG)
900
Product name
Wave soldering machine
PCB width
Max.50~250mm
Preheating Length
900mm
Tin Pot temperature
Room temperature~300℃
Preheating Method
Hot Air
Operating Power
4KW
Tin Pot Capacity
160-200Kg
Control Method
PC+Siemens PLC
Air Source
4-7Kg/cm2 12.5L/min
Component Max Height
100mm
